Running and using Go-Ethereum

Most of the time, we have been using the Brownie development environment for our tests so far, and with it the Ganache Ethereum client that Brownie runs behind the scenes. For some applications, it is useful to have other clients at our disposal. The Go-Ethereum client (geth) is the most commonly used client at the time of writing, and today we take a slightly more detailed look at how to run and configure it.

Getting started

We have already installed the geth binary in a previous post, so I assume that the geth binary is still on your path. However, geth is evolving quickly – when I started this series, I used version 1.10.6, but in the meantime, 1.10.8 has been released which contains an important bugfix (for this vulnerability which we have analyzed in depth in a previous post ), so let us use this going forward. So please head over to the download page, get the archive for version 1.10.8 for your platform (here is the link for Linux AMD64), extract the archive, copy the geth binary to a location on your path and make it executable.

Geth stores blockchain data and a keystore in a data directory which can be specified via a command line flag. We will use ~/.ethereum, and it is easier to follow along if you start over with a clean setup, so if you have used geth before, you might want to delete the contents of the data directory before proceeding. To actually start the client, we can then use the command

geth --dev \
     --datadir=$HOME/.ethereum \
     --http \
     --http.corsdomain="*" \
     --http.vhosts="*" \
     --http.addr="0.0.0.0" \
     --http.api="eth,web3"

For the sake of convenience, I have put that command into a script in the tools directory of my repository, so if you have a clone of this directory, you could as well run ./tools/run_geth. Let us go through the individual flags that we have used and try to understand what they imply.

First, there is the dev flag. If you start geth with this flag, the client will actually not try to connect to any peers. Instead, it will create a local blockchain, with a genesis block which is created on the fly (here). In addition, geth will create a so-called developer account (or re-use an existing one). This account shows up at several places. It will be the first account in the keystore managed by geth and therefore the first account that the API method eth_accounts will return. This account (or rather the associated address) will also be used as the etherbase, i.e. as the address to which mined Ether will be credited. Finally, the genesis contains an allocation of 2256 – 9 Wei (the genesis block will also contain allocations for the nine pre-compiled contracts).

The next flag is the data directory, which we have already discussed. The following couple of flags are more interesting and configure the HTTP endpoint. Geth offers APIs over three different channels – HTTP, WebSockets (WS) and a local Unix domain socket (IPC). Whereas the IPC endpoint is enabled by default, the other two are disabled by default, and the http flag enables the HTTP endpoint.

The next three flags are important, as they determine who is allowed to access this API. First, http.address is the address on which the client will be listening. By default, this is the local host (i.e. 127.0.0.1), which implies that the client cannot be reached from the outside world. Especially, this will not work if you run geth inside a docker container or virtual machine. Specifying 0.0.0.0 as in the example above allows everybody on the local network to connect to your client – this is of course not a particularly secure setup, so modify this if you are not located on a secure and private network.

In addition, geth also uses the concept of a virtual host to validate requests. Recall that RFC7320 defines the HTTP header field Host which is typically used to allow different domains to be served by one web server running on one IP address only. This field is added by web browsers to requests that are the result of a navigation, but also the requests generated by JavaScript code running in the browser. When serving an incoming request, geth will validate the content of this header field against a list configured via the http.vhosts flag. This flag defaults to “localhost”. Thus, if you want to serve requests from outside, maybe from a web browser running on a different machine in your local network, you have to set this flag, either to the domain name of your server or using the wildcard “*” to accept incoming requests regardless of the value of the host header.

Finally, there is the CORS domain flag http.corsdomain. CORS is the abbreviation for cross-origin request surgery and refers to an attack which tries to access a server from JavaScript code loaded from a different domain. To prevent this sort of attack, browsers ask a server upfront before sending such a request whether the server will accept the request by submitting a so-called pre-flight request. When we develop our frontend later on, we will need to make sure that this pre-flight request is successful, so we need to include the domain from which we will load our JavaScript code to the list that we configure here, or, alternatively, also use a wildcard here. If you want to learn more about CORS, you might want to read this documentation on the Mozilla developer network.

The last flag that we use determines which of the APIs that geth offers will be made available via the HTTP endpoint. The most important API is the eth API, which contains all the methods that we need to submit and read transactions, get blocks or interact with smart contracts. In addition, it might be helpful to enable the debug API, which we will use a bit later when tracing transactions. There are also a few APIs which you almost never want to make available over the network like the personal API which allows you to access the accounts maintained by the client, or the admin API.

Using the geth console

We have just mentioned that there are some APIs which you would typically not want to make accessible via the API. Instead, you usually access these APIs via the IPC endpoint and the geth console. This is a JavaScript-based interactive console that allows you to invoke API methods and thus interact with a running geth client. To start the console, make sure that the geth client is running, open a separate terminal window and enter

geth attach ~/.ethereum/geth.ipc

Note that the second argument is the Unix domain socket that geth will create in its data directory. To see how the console works, let us play a bit with accounts. At the prompt, enter the following commands.

eth.blockNumber
eth.accounts
eth.getBlockByNumber(0)

The first command will return the block number for the block at the head of the chain. Currently, this is zero – we only have the genesis block, no other blocks. The second command displays the list of accounts managed by the node. You should see one account, which is the developer accounts mentioned earlier. The third command displays the genesis block, and you will see that the extra data also contains the developer account.

The accounts managed by the node can be controlled using the personal API. An important functionality of this API is that accounts can be locked, so that they can no longer be used. As an example, let us try to lock the developer account.

dev = eth.accounts[0]
personal.lockAccount(dev)

Unlocking the account again is a bit tricky, as this is not allowed while the HTTP endpoint is being served. So to unlock again, you will have to shutdown geth, start it again without the HTTP flags, attach again and execute the command

personal.unlockAccount(eth.accounts[0], "")

Note the second argument – this is the password that has been used to lock the account (at startup, geth creates the development account with an empty passphrase, alternatively a passphrase can be supplied using the —password command line flag).

Finally, let us see how to use the console to create additional accounts and transfer Ether to them.

dev = eth.accounts[0]
alice = personal.newAccount("secret")
value = web3.toWei(1, "ether")
gas = 21000
gasPrice = web3.toWei(1, "gwei")
txn = {
        from: dev,
        to: alice,
        gas: gas,
        gasPrice: gasPrice,
        value: value
}
hash = eth.sendTransaction(txn)
eth.getTransactionReceipt(hash)
eth.getBalance(alice)

You could now proceed like this and set up a couple of accounts, equipped with Ether, for testing purposes. To simplify this procedure, I have provided a script that sets up several test accounts – if you have cloned the repository, simply run it by typing

python3 tools/GethSetup.py

Geth and Brownie

What about Brownie? Do we have to say good-bye to our good old friend Brownie if we choose to work with geth? Fortunately the answer is no – Brownie is in fact smart enough and will automatically detect a running geth (in fact, a running Ethereum client) when it is started and use it instead of launching Ganache. Let us try this. Make sure that geth is running and start Brownie as usual.

brownie console

At this point, it is important that we have enabled the web3 API when starting geth, as Brownie uses the method web3_clientVersion to verify connectivity at startup. If everything works, Brownie will spit out a warning that the blockchain that it has detected has a non-zero length and greet you with the usual prompt.

Great, so let us transfer some Ether to a new account as we have done it before from the console to see that everything works.

dev = accounts[0]
bob = accounts.add()
dev.transfer(to=bob, amount=web3.toWei(1, "ether"))

Hmm…this does not look good. It appears that Brownie has created a transaction and sent it, but is now waiting for the receipt and does not receive it. To understand the problem, let us switch again to a different terminal and start the geth console again. At the console prompt, inspect the pending transactions by running

txpool

The output should show you that there is one pending transaction (which you can also inspect by using eth.getTransaction) which is not included in a block yet. If you look at this transaction for a second, you will find that there are two things that look suspicious. First, the gas price for the transaction is zero. Second, the gas limit is incredibly high. If you inspect the last block that has been mined, you will find that the gas limit is exactly the gas limit of the last block that has been mined successfully.

Why is this a problem? The gas limit for a new block is determined by geth aiming at a certain target value. At the moment, this target value is lower than the gas limit of the genesis block, meaning that geth will try to decrease the gas limit with each new block (the exact algorithm is here). Thus the gas limit for the new block that the miner tries to assemble is lower than that for the previous one and therefore lower than the gas limit of our transaction, so that the transaction will not fit into the block and the miner will ignore it.

Let us try to fix this. First, we need to replace our pending transaction. The easiest way to do this is to use the geth console. What we need to do is to get the transaction from the pool of pending transactions, correct the gas limit and increase the gas price, so that the miner will pick up this transaction instead of the previous one. We also set the value to zero, so that the transaction will effectively be cancelled.

txn = eth.pendingTransactions[0]
txn.gas = eth.estimateGas(txn)
txn.gasPrice = web3.toWei(1, "gwei")
txn.value = 0
eth.sendTransaction(txn)

Note that we did not change the nonce, so our transaction replaces the pending one. After a few seconds, Brownie should note that the transaction has been dropped and stop waiting for a receipt.

The reason for our problem is related to the way how Brownie determines the gas limit and gas price to be used for a transaction. When a transaction is created, Brownie tries to figure out a gas limit and gas price from the network configuration. For the gas limit, the default setting is “max”, which instructs Brownie to use the block gas limit of the latest blocks (which will be cached for one hour). For the gas price, the default is zero. To make Brownie work with geth, we need to adjust both settings. In the console, enter

network.gas_limit("auto")
network.gas_price("auto")

When you now repeat the commands above to transfer Ether, the transaction should go through. For versions of Brownie newer than version 1.15.2, however, you will receive an error message saying that the sleep method is not implemented by geth. The transaction will still work (the error comes from this line of the code which is executed in a separate thread initiated here), so the error message is only annoying, however you might want to downgrade to version 1.15.2 if you plan to work with Brownie and geth more often (it appears that the problem was introduced with this commit).

Note that the settings for the gas price and the gas limit that we have made enough will be lost when we restart Brownie. In order to make these changes permanent, you can add them to the configuration file for Brownie. Specifically, Brownie will, upon startup, load configuration data from a file called brownie-config.yaml. To set the gas price and the gas limit, create such a file with the following content

networks:
    default: development
    development:
        gas_limit: auto
        gas_price: auto

Here we adjust the configuration for the network development which we also declare as the default network and set the gas limit and the gas price to “auto”, instructing Brownie to determine a good approximation at runtime.

This closes our post for today. We have learned how to run geth in a local development environment, discussed the most important configuration options and seen how we can still use Brownie to work with transactions and contracts. In the next post, we will start to design and build our NFT wallet application and first try to understand the overall architecture.
