Basics of quantum error correction

Do usable universal quantum computers exist today? If you follow the recent press releases, you might believe that the answer is “yes”, with IBM announcing a 50 qubit quantum computer and Google promoting its Bristlecone architecture with up to 72 qubits. Unfortunately, the world is more complicated than this – time to demystify the hype a bit.

The need for error correction

The important point is that it is not just the number of qubits that matters, but also their quality. When we study quantum algorithms like Shor’s algorithm, we are working with idealized qubits that behave exactly the way an isolated two-state quantum system is supposed to behave – these idealized qubits are often called logical qubits. However, in a real world implementation, there is no fully isolated two-state quantum system. Every system interacts to some extent with the environment, an interaction that we can try to reduce to a minimum, for instance by cooling our device down to very low temperatures, but never fully avoid. A trapped ion could, for instance, interact with radiation entering our device from the environment, and suddenly is part of a larger quantum system, consisting of the ion, the photons making up the radiation and maybe even the source of the photon. This will introduce errors into our system, i.e. deviations of the behavior of the system from the idealized theoretical model.

In addition to unwanted interactions with the environment, other errors could creep into our computation. When manipulating qubits to realize gates, we might make mistakes, for instance by directing a microwave pulse with a slightly incorrect frequency at our qubit, and we can make mistakes during each measurement.

Thus the real qubits in a quantum computer – called physical qubits – are prone to errors. These errors might be small for one qubit, but they tend to propagate through the circuit and add up to a significant error that will render the result of our quantum computation unusable. Thus we need error correction, i.e. the ability to detect and correct errors during our computation.

So how would you do this? Of course, errors can also occur in classical systems, and there are well developed methods to detect and correct them. Unfortunately, these approaches typically rely on the ability to copy and measure individual bits. This is easy for a classical bit, but more complicated for a qubit, as a measurement will collapse our system into an eigenstate of the observed operator and thus interfere with quantum algorithm.

The good news is that quantum error correction is still possible. In this post, I will try to explain the basics, before we then dive into more advanced topics in the next few posts.

Encoding logical states

In order to understand the basic ideas and structures behind quantum error correction, it is useful to study a simplified example – the three qubit code. To introduce this code, let us suppose that we have access to a communication channel across which we can send individual qubits from one quantum device to another one. Suppose further that this transmission is not perfect, but is subject to a bit flip error with a probability p. Thus, with probability p, a one-qubit state |\psi \rangle will be changed to X |\psi \rangle during transmission, where X is the usual bit flip operator, and with probability 1-p, the transmission does not change the state. The aim is to construct an encoding of a qubit such that these errors can be detected and corrected.

To achieve this, we encode every single qubit state in a three-qubit state before transmitting it. Thus we use the following encoding

|0 \rangle  \mapsto |000 \rangle

|1 \rangle  \mapsto |111 \rangle

It is not difficult to see that this encoding can in fact be realized by a unitary circuit – the circuit below will do the trick.

ThreeBitCode

To transmit one qubit, we use this encoding to obtain a three-qubit message. We then send those three qubits through our communication channel. After the transmission, we apply a procedure known as syndrome measurement, using the following circuit.

SyndromeMeasurement

Let us see what this circuit is doing. First, let us suppose that the original qubit was |0 \rangle, encoded as |000 \rangle, and no error did occur during the transmission. Then the three qubits at the top of the circuit will still be |000 \rangle. In this case, the CNOT gates act as the identity, and the overall state after passing the circuit is

|000 \rangle |00 \rangle

Similarly, if the original qubit is |1 \rangle and no error occurred, all CNOT gates will act as inversion. Thus the ancilla qubits will be inverted twice, and we end up with the state

|111 \rangle |00 \rangle

The situation is a bit different if a bit flip error has affected one of the qubits during the transmission, say the first one. Suppose the original state was again |0 \rangle. After encoding and transmission with a bit flip on the first qubit, we will receive the state |100 \rangle. Therefore both ancilla qubits will be inverted, and we obtain the state

|100 \rangle |11 \rangle

Let us now generalize these considerations. Assume that we are encoding the state a |0 \rangle + b |1 \rangle, so that the encoded state will be a |000 \rangle + b |111 \rangle. When we go through the above exercise for all possible cases, we arrive at the following table that shows the transmission error and the resulting state after passing the syndrome measurement circuit.

Error Resulting state
No error (a |000 \rangle + b |111 \rangle ) |00 \rangle
Bit flip on first qubit (a |100 \rangle + b |011 \rangle ) |11 \rangle
Bit flip on second qubit (a |010\rangle + b |101 \rangle ) |10 \rangle
Bit flip on third qubit (a |001\rangle + b |110 \rangle ) |01 \rangle

Now let us see what happens if we measure the ancilla qubits. First, note that all the states are already eigenstates for the corresponding measurement operator. Thus measuring the ancilla qubits will not change the state of the first three qubits and it will not reveal any information on the encoded state. The second important observation is that the value of the ancilla qubits tells us the exact error that has occurred. Thus we have found a way to not only find out that an error has occurred without destroying our superposition, but also to figure out which qubit was flipped. Given that information, we can now apply a bit flip operator once more to the affected qubit to correct the error. Again, this will not reveal the values of a and b and not collapse our state, and we can therefore continue to work with the encoded quantum state, for instance by running it through the inverse of the encoding circuit to get our original state back.

More general error models

So what we have found so far is that it is possible, also in the quantum world, to detect and protect against pure bit flip errors without destroying the superposition. But there is more we can learn from that example. In fact, let us revisit our original assumption that the only thing that can go wrong is that the operator X is applied to some of the qubits and allow a more general operator. Suppose, for instance, that our error is represented by applying to at most one of our qubits the operator

E = (1-\epsilon) 1 + \epsilon X

for a small \epsilon . In contrast to our earlier assumption that the error operator is discrete, i.e. is either applied or not applied, this operator is now continuous, depending on the parameter \epsilon, i.e. it looks as if we had to deal with a full continuous spectrum of errors. A short calculation shows that after transmitting and applying the syndrome measurement circuit above, the state of our quantum system will now be

(1-\epsilon)(\alpha |000 \rangle + \beta |111 \rangle)|00\rangle + \epsilon (\alpha |100 \rangle + \beta |011\rangle) |11 \rangle

Now let us again apply a measurement of the ancilla qubits. Then, according to the laws of quantum mechanics, the system will collapse onto an eigenstate, i.e. it will – up to normalization – end up in one of the states

(\alpha |000 \rangle + \beta |111 \rangle)|00\rangle

and

(\alpha |100 \rangle + \beta |011\rangle) |11 \rangle

But these are exactly the states in which we end up if no error occurs or a single bit flip error occurs. Thus, our measurement forces the system to somehow decide whether an error occurred or not and if yes, which error occurred – we are opening the box in which Schrödingers cat is hidden. This is a very important observation often referred to as the digitization of errors – it suffices to protect against discrete errors as the syndrome measurement will collapse any superposition of different errors states.

So far we have worked with a code which is able to protect against a bit flip error. But of course this is not the only type of error that can occur. At the first glance, it looks like there is a vast universe of potential errors that we have to account for, as in theory, the error could be any unitary operator. However, using arguments similar to the discussion in the last paragraph, one can show that it suffices to protect against two types of errors: the bit flip error discussed above and the phase flip error, represented by the matrix

Z = \begin{pmatrix} 1 & 0 \\ 0 & -1 \end{pmatrix}

Note that the phase flip error has no classical equivalent, other than the bit flip error which can classically be interpreted as a bit flipping from one to zero or vice versa randomly. The first error correction code that was able to handle both, bit flip errors and phase flip errors (and combinations thereof, ), and therefore any possible type of error (as long as the number of errors is limited) was described in 1995 by P. Shor. This code uses nine qubits to encode one logical qubit and is somehow a repeated application of the three bit code, based on the observation that the Hadamard transform turns a bit flip error into a phase flip error and vice versa. Later, different types of codes were discovered that are also universal in the sense that they protect against any potential one qubit error, i.e. against any error that only affects one qubit.

Let us now look at the structure that these codes have in common. First, the encoding can be described as identifying a 2-dimensional subspace C, called the code space, in the larger space spanned by all qubits. In the case of the three qubit code, the code space is spanned by the states |000 \rangle and |111 \rangle, corresponding to a logical zero and a logical one. More generally, the space C can have dimension 2n and the full Hilbert space can have dimension 2k, in which case we can encode n qubits in a larger set of k qubits (in the nine qubit code example, k = 9 and n = 1).

Hence the code space is spanned by a set of 2n basis vectors |\psi_i \rangle that we call code words. In the case n = 1, it is common practice to denote the codewords by |0 \rangle_L and |1 \rangle_L to indicate that they represent a logical qubit encoded using k physical qubits.

In addition, there is a set of error operators, i.e. a finite set of operators \{ E_\alpha\} like the phase flip or bit flip operators acting on the larger Hilbert space. These operators represent the impact of discretized noise and will generally move the code words out of the code space, i.e. they will rotate the code space onto different subspaces of the entire Hilbert space.


In order for a code to be useful, we of course need a relation between code space and errors that tells us that the errors can be detected and corrected. What are these conditions? A first condition is that no matter which errors occur, we can still tell the code words apart. This is guaranteed if the various error operators map different code words onto mutually orthogonal subspaces, in other words if

\langle \psi_i | E_\alpha^{+} E_\beta | \psi_j \rangle = 0

whenever i \neq j and for all \alpha, \beta. Thus, even in the presence of errors, the different code words will never overlap.

What about the case that both code words are the same? It is tempting to ask for the condition

\langle \psi_i | E_\alpha^{+} E_\beta | \psi_i \rangle = \delta_{\alpha \beta}

i.e. to require that different errors map the same codeword to orthogonal subspaces. This would make recovery very easy. We could perform the measurements that correspond to projections onto these subspaces to detect the error and correct them by applying the inverse of the error operator. However, this condition is too restrictive. In the case of the nine qubit code, for example, it might very well happen that two different errors map a code word to the same state. However, the same applies for the correction, i.e. we do not have to distinguish between these two errors as the act similarly on the code space. Therefore, a more general condition is usually used which captures this case:

\langle \psi_i | E_\alpha^{+}E_\beta | \psi_j \rangle = C_{\alpha\beta} \delta_{ij}

for a hermitian matrix C_{\alpha \beta}. If the matrix has full rank, the code is called non-degenerate, otherwise – as in the case of the nine qubit code – the code is called degenerate.

Of course this encoding generates some overhead. To represent one logical qubit, we need more than one physical qubit. For the Shor code, we have to use nine physical qubits to encode one logical qubit. It is natural to ask what the minimum overhead is that we need. In 1996, Steane discovered a code that requires only seven physical qubits. In the same year, a code that requires only five qubits was presented and it was shown that this is a lower bound, i.e. there is no error correction code that requires less than five qubits.

So there is an unavoidable overhead – and the situation is even worse. To implement error correction, you need again quantum gates, which can of course also experience errors. Thus you need additional circuitry to protect the error correction against errors, which can again introduce errors and so forth. That there is a way out of this vicious circle is not obvious and the content of the famous threshold theorem that we will study in a later post – but even this way out is very hard to implement and might require thousands of physical qubits to implement one single logical qubit.

So even with a 72 qubit device, we are still far away from implementing only one logical qubit – and having a few thousand logical qubits to use Short’s algorithm to break an RSA key with a realistic key length is yet another story. So it is probably a good idea to take claims about universal supremacy of quantum computing within a few years with a grain of salt.

In this post, we have looked at some of the essential ideas behind quantum error correction, i.e. the ability to detect and correct errors. However, this is not enough to build a reliable quantum computer – after all, adding an error correction circuit introduces additional qubits that can also create new errors. In addition, we need to be able to perform calculations on our encoded states. So there is more that we need for fault-tolerant quantum computing which is the topic of the next post.
